LST-A5R

16-seat full-load-bearing electric minibus, 340 km WLTC

16seats
Seating capacity: 340km
WLTC range: 86.1kWh LFP
Battery: 100km/h
Max speed

16 seats in a 2 + 4 + 3 + 3 + 4 layout
86.1 kWh LFP pack, 340 km WLTC range
Full-load-bearing body with double-wishbone front suspension
10.1-inch multimedia screen and ESC with AUTOHOLD
5-year / 200,000 km powertrain warranty

Request a quotation WhatsApp

Right-hand drive as standard. Left-hand drive available on request for fleet orders. Full specification sheet issued with quotation.

Overview

Built for the duty cycle, not the brochure

The LST-A5R is the heavy-duty member of the range. An 86.1 kWh LFP pack and a 50/100 kW permanent-magnet synchronous motor deliver a WLTC range of 340 km with seating for 16 in a 2 + 4 + 3 + 3 + 4 arrangement. A full-load-bearing body, double-wishbone front suspension and ESC with AUTOHOLD give it the structural stiffness and stability that daily high-occupancy duty demands.

Full-load-bearing body

A separate ladder-type chassis under a load-bearing body gives the A5R the torsional rigidity that 16 passengers plus luggage on poor roads demands — and makes it straightforward to service.

Double-wishbone front end

Independent double-wishbone front suspension keeps wheel geometry stable under load, cutting tyre wear and improving straight-line stability at highway speed.

Highest payload in the range

A 3,450 kg gross weight against a 2,350 kg kerb weight leaves 1,100 kg for passengers, luggage and air conditioning load — headroom that matters in hot climates.

Passenger comfort as standard

Negative-ion air purification, drum heater for the passenger area and a 10.1-inch display are fitted as standard, not sold as extras.

Technical data

Full specifications

Dimensions & weight

Overall dimensions (L × W × H)	5,380 × 1,880 × 2,285 mm
Wheelbase	3,110 mm
Curb weight	2,350 kg
Full load mass	3,450 kg
Seating capacity	16 (2 + 4 + 3 + 3 + 4)
Bodywork	Full-load-bearing
Steering position	Right-hand drive
Vehicle source code / model	Q1002 / SLK6540RBEV

Powertrain & battery

Motor type	Permanent magnet synchronous motor
Rated / peak power	50 / 100 kW
Rated / peak torque	125 / 270 N·m
Driving method	Rear-wheel drive
Battery type	LFP (lithium iron phosphate)
Battery capacity	86.1 kWh
WLTC range	340 km
Maximum speed	100 km/h
Charging interval (30 – 100%)	80 minutes
Slow charging power	6.6 kW, charging station standard
Battery heating & energy recovery	Standard

Chassis & safety

Front suspension	Double-wishbone independent suspension
Rear suspension	Variable-stiffness leaf spring (4 pieces)
Brakes	Disc type, hydraulic with vacuum servo
ABS + EBD	Standard
ESC / AUTOHOLD	Standard
EPS electric power steering	Standard
Parking brake	EPB (electric parking brake)
Tyres	195R16C on aluminium rims
Tyre pressure monitoring	Optional
Seat belts	Three-point front and rear, two-point passenger area

Body & equipment

Doors	Rear hatch, left aircraft door; electric windows throughout
Body panels	PVC passenger-area box panels
Multimedia	10.1-inch large screen, LCD instrument panel
Driver assistance	Reversing camera and reverse sensor
Air treatment	Box-type negative-ion air purifier
Climate	Cold and warm A/C; PTC driver heating, drum heater for passengers
Lighting	LED headlights, front fog lights; automatic headlights optional
Charging	GB standard port; 12 V outlet and USB charging
Warranty	5 years or 200,000 km — battery pack, motor and MCU

Figures are taken from the current production specification. Options shown are available at additional cost and subject to market homologation. Final specification is confirmed in the sales contract.
